DF651 BMW Fault Code

Description:

The Throttle Position sensor signals the Engine Control Module as to the current position of the engine throttle valve.
The current throttle valve opening is based on the driver's input from the gas pedal.

The ECM uses the information from this sensor to help calculate fuel delivery and spark timing.

DF651 Code Symptoms :

OBD DF651 code and tailpipe testing are two different approaches to identify vehicles in need of repair. The OBD system looks for broken or malfunctioning emissions control components and DF651, while tailpipe tests sample a vehicle's exhaust to see if it is above or below certain prescribed limits. Given the robust nature of today's emissions control components, it is entirely possible for an individual component to malfunction without leading to an immediate increase in emissions at the tailpipe.

In such cases, other components (like the catalyst) can temporarily compensate for the part that is broken however, these other components can only do double duty for so long before they, too, begin to malfunction. In addition, OBD also monitors for and other malfunctions in the fuel system problems that traditional tailpipe tests were not designed to identify. Most state and local areas also include a gas cap pressure test as part of an emission inspection.

Diagnosis And Repairing DF651

DF651 OBD2 reports a sensor fault, replacement of the sensor is unlikely to resolve the underlying problem. The fault is most likely to be caused by the systems that the sensor is monitoring, but might even be caused by the wiring to the sensor itself.

How to fix DF651 code ?

• Faulty Air Flow Meter
• Faulty Air fuel ratio (A/F) Sensor 1 Bank 1
• Clogged or faulty fuel injector (s)
• Intake Valve Timing Control Solenoid Valve circuit poor electrical connection

At this point we are assuming that the fuses and relays are good. You will need to locate the PCM/TCM and the power input signal circuit using your vehicle information source.

Unplug the connector from the PCM/TCM, place the ignition switch in the ON position, and probe the appropriate circuit with the positive test lead of the DVOM.
